hand tools

Designed for notching 90 degree up to 20 gauge mild steel with minimal effort. The No. 541 Series notcher is capable of a 1″ depth of notch featuring a built-in metal stop. Includes blade and die. 145065410

Designed for fast, accurate 32 degree notch on sheet metal. Hook design of jaws permits notching to exact desired depth without slippage and with minimum effort. Spring-return jaws. 145061410

A light, fast-working, handy-size tool for dovetailing during installation of collars, stubs, Y-joints, etc. Spring-return jaws. Cuts notch and fold tab down square in one easy motion. 145061210

For straight and parrallel incisions eg. square seam folding on wall connection edges, the notching length of 1 3/8" enables continous uninterrupted cuts, suitable for sheet steel up to 22 Gauge.

00371000- 1.17LB 11-3/4"

The No. 44 has wide, deep jaws machined for a smooth parallel fit and forms precise folds and seams. The rugged design features strong, lasting drop-forged steel construction and has a 3 1/2″ wide blade. 148060440

The No. 793 has wide, deep jaws machined for a smooth parallel fit and forms precise folds and seams. The rugged design features strong, lasting drop-forged steel construction and has a 3 1/2″ wide blade with adjustable depth gauge. 148067930

45° bent, lap joint, precoated handles.

01090040- 1.32LB, JAW WIDTH: 1-5/8" INSERTION DEPTH: 1-7/8"

01090060- 1.54LB, JAW WIDTH: 2-3/8" INSERTION DEPTH: 1-7/8"

01090080- 2.04LB, JAW WIDTH: 3-1/8" INSERTION DEPTH: 1-7/8"

90° bent, lap joint, precoated handles.

01092040- 1.32LB, JAW WIDTH: 1-5/8" INSERTION DEPTH: 2-1/8"

01092060- 1.65LB, JAW WIDTH: 2-3/8" INSERTION DEPTH: 2-1/4"

01092080- 2.32LB, JAW WIDTH: 3-1/8" INSERTION DEPTH: 2-5/8"

45° bent, lap joint, precoated handles.

01090100- 2.54LB, JAW WIDTH: 3-7/8" INSERTION DEPTH: 2-5/8"

Straight, lap joint, precoated handles.

01100080- STAKED JOINT, 1.87LB, 3-1/8"

01100081- LAP JOINT, 1.76LB, 3-1/8"

Straight, lap joint, precoated handles.

01080100- 2.54LB, JAW WIDTH: 3-7/8" INSERTION DEPTH: 2-1/2"

Straight, lap joint, precoated handles.

01080101- 1.92LB, JAW WIDTH: 3-7/8" INSERTION DEPTH: 2-1/4"

Lap joint, precoated handles.

01170060- 2.76LB, JAW WIDTH: 2-3/8" INSERTION DEPTH: 2-5/8"

Lap-on joint, precoated handles.

01070250- 0.99LB, 9-7/8",

JAW WIDTH: 1-1/8"

Straight, lap joint.

01141120- 4.08LB, JAW WIDTH: 4-3/4" INSERTION DEPTH: 4-7/8"

01141140- 4.23LB, JAW WIDTH: 4-3/4" INSERTION DEPTH: 4-7/8"

01141160- 6.62LB, JAW WIDTH: 6-1/4" INSERTION DEPTH: 6-7/8"

01141180- 7.50LB, JAW WIDTH: 7-1/8" INSERTION DEPTH: 6-7/8"

01141200- 7.17LB, JAW WIDTH: 7-7/8" INSERTION DEPTH: 7-1/4"

Straight, skewed on one side
depth of insertion 6 7/8", jaw width 7 1/8".

01140181- STAKED JOINT, 7.50LB, 6-7/8"

01141181- LAP JOINT, 7.50LB, 6-7/8"

Bent, lap joint.

01161120- 4.08LB, JAW WIDTH: 4-3/4" INSERTION DEPTH: 4-3/8"

01161140- 4.19LB, JAW WIDTH: 4-3/4" INSERTION DEPTH: 4-3/8"

01161160- 6.50LB, JAW WIDTH: 6-1/4" INSERTION DEPTH: 6-1/4"

01161180- 6.73LB, JAW WIDTH: 7-1/8" INSERTION DEPTH: 6-1/4"

01161200- 7.06LB, JAW WIDTH: 7-7/8" INSERTION DEPTH: 6-1/4"

This manually-operated squareseamfolder joins SPM 30/80 profiles, smooth lead-on avoid marks at the transitions. It is easy to handle when working extreme angular sheating, the tool may also be used for vertical as well as for horizontal beads. Durable baked epoxy finish.

91100000- 4.41LB, 8-2/3"

For prefabricated SPM-profiles on small
roof areas. For efficient use and transportation handles can be adjusted in length in 3 steps. Durable baked epoxy finish.

91101000- 7.72LB, 8-5/8"

Allows simple and quick shaping of locked square seam into double seam in just one operation. Do not use to close a square seam! Durable baked epoxy finish.

91170000- 5.51LB, 8-2/3"

Suitable for sheet metal up to 3/8“ this is the all-round-tool for roofer, plumber, tin smith and panelbeater, adjustable stops support making edges from 1/4" to 3/4" freehand, with a tool width of 2 3/8" you bend sheet metal in any length. Durable baked epoxy finish.

91110000- 1.54LB, 2-1/8"

Stainless steel. HRC 59 (blue)

01232301- RIGHT, 1.61LB, 11-3/4"

01233301- LEFT, 1.61LB, 11-3/4"

 Stainless steel, compound leverage,
for stainless steel sheets, HRC 58-60, bicomponent grip.

01282240- STRAIGHT, 0.63LB, 10-1/4"

Stainless steel, compound leverage,
for stainless steel sheets, HRC 58-60, bicomponents grip.

01280240- RIGHT, 0.83LB, 9-1/2"

01281240- LEFT, 0.82LB, 9-1/2"

Stainless steel, compound leverage,
for stainless steel sheets, HRc 58-60, bicomponents grip.

01290240- RIGHT, 0.86LB, 9-1/2"

01291240- LEFT, 0.86LB, 9-1/2"

Stainless steel, compound leverage, for stainless steel sheets, HRc 58-60, bicomponents grip.

01290260- RIGHT, 1.20LB, 10-1/4"

01291260- LEFT, 1.20LB, 10-1/4"

Special high quality steel, double compound leverage, for stainless steel sheeets, HRC 61.

01292260- RIGHT, 0.99LB, 10-1/4"

01292261- LEFT, 0.99LB, 10-1/4"

Special high quality steel, double compound leverage, for stainless steel sheets, HRC 61.

01294260- RIGHT, 1.22LB, 10-1/4"

01294261- LEFT, 1.22LB, 10-1/4"

Special high quality steel, double compound leverage, for stainless steel sheets, HRC 61.

01290180- RIGHT, 0.88LB, 7-1/8"

01290181- LEFT, 0.88LB, 7-1/8"

PVC, angular.

01674000- 3-1/4" x 3-1/4" x 5-7/8" 19.40LB

PVC, round.

01678060- 2-3/8" x 4-1/4" 15.87OZ

01678070- 2-3/4" x 4-3/4" 19.05OZ

01678080- 3-1/4" x 5-1/2" 27.87OZ

PVC, angular.

01678145- 5-3/4" x 1-3/8" x 3" 19.40OZ

01678155- 6-1/8" x 1-3/8" x 3-3/8" 21.16oz

With metal ring.

01676000- 2-3/8" 13.05OZ

Edged, head made of beech, with hardwood handle.

01673000- 3-1/2" x 2" 20.46OZ

Round, head made of beech, with hardwood handle.

01672000- 3-1/8" x 6-1/4" 19.40OZ

For fender and high-crowned panel dinging or bumping. Both high and low-crown faces for "on or off dolly" work. Faces, 1-1/4" and 1-9/16". Round heads, 6" overall. Weight 1.04lbs.

150G- Wood Handle

150FG- Fiberglass Handle

Two high-crowned faces for concave surfaces on doors, rear quarter panels, fenders and hoods. Faces 1-1/8", 6" overall. Weight 1.02lbs.

152G- Wood Handle

Excellent for finishing. Cross peen used for working in sharp corners around mouldings and for caulking. Round face-- 1-9/16" diameter. Chisel-- 3" long. Weight .87lbs.

153G- Wood Handle

153FG- Fiberglass Handle

Excellent for finishing. Cross peen used for working in sharp corners around mouldings and for caulking. Well balanced curved chisel for work in close places. Round face-- 1-9/16" diameter. Chisel-- 3" long. Weight .85lbs.

153GB- Wood Handle

153FGB- Fiberglass Handle

Blunt point-- long reach. For low spots on high crown panels and other work with long reach. Will not pick holes in the metal. Round face-- 1-9/16" diameter. Blunt point 3" long. Weight .81lbs.

158GM- Wood Handle

158FGM- Fiberglass Handle

Sharp point- long reach. For low spots on high crown panels and other work with long reach. Round face-- 1-9/16" diameter. Sharp point 3" long. Weight .79lbs.

158GMS- Wood Handle

For heavy gauge truck fenders and panels. Also used in straightening reinforcements, braces, etc. Faces, 1-1/4" round and 1-3/16" square head, 4" overall. Weight 1.1lbs.

160G- Wood Handle

160FG- Fiberglass Handle

Short-reach, lightweight. One low-crown, square facec. Lightest dinging hammer in line. Faces, 1-1/4" round and 1-3/16" square. Head, 4" overall. Weight .83lbs.

161G- Wood Handle

161FG- Fiberglass Handle

For work in close quarters. Expertly machined serrations on the round face. Plain square face, 1-1/8" round serrated face, 1-1/4" diameter. 4" overall. Weight .78lbs.

162G- Wood Handle

162FG- Fiberglass Handle

Blunt point, short reach. For low spots in high-crown panels and other work with small clearance. Face, 1-9/16" round point, 5/32" radius. Length of pointed end, 2" head, 4" overall. Weight .75lbs.

164G- Wood Handle

164FG- Fiberglass Handle

Used to bump odd fender or bumper contours. Round face-- 1-9/16" diameter peen end 3/16" x 7/8". 5" overall head length. 12" handle. Weight .91lbs.

168G- Wood Handle

168FG- Fiberglass Handle

Ideal for forming radiuses, contours and curves- restoration, bike tanks. High crown face-- 1-9/8" diameter. 2-1/4" radius. Peen end 3/16" x 1". 5" overall head length. 12" handle. Weight 1.0lbs.

168HC- Wood Handle

168HCFG- Fiberglass Handle

For finishing and caulking. Round face-- 1-7/8" diameter. 4-1/2" overall head length. 13" handle. Weight 1.0lbs.

169G- Wood Handle

169FG- Fiberglass Handle

Bends from 90° profiles to maximum 180°, bending height: min. 3/8" max. 1 5/8".No alignment or adjustment work necessary, expandable with a second Disk Roller and adapter to become a Double Disk Roller, bends sheets with the max. of 20 Gauge strength, application of eaves and gutter flashings, alterations, etc.

91611000- 2.05LB, 6-3/4" x 2-1/4"

Easy-to-read scale (mm + inch), loops to hang from work belt, expandable with a second Standard Edge Roller and adapter to become a dual bending machine, bending height: 1/4" - 7 7/8", suitable for small radii.

91602000- 3.07LB, 11-3/4" x 4-3/8"

Easy-to-read scale (mm + inch), loops to hang from work belt, bending height: 1/4" – 7 7/8", suitable for small radiuses.

91620000- 7.72LB, 14-5/8" x 8-7/8"

Equipped with four guiding rollers,
easy-to-read scale (mm + inch), loops to hang from work belt, expandable with a second Premium Edge Roller and adapter to become a dual bending machine, bending height: 1/4" – 7 7/8".

91603000- 3.53LB, 11-3/4" x 5-7/8"

Mobile edge rolling machine for edging and bending of sheet metal, applicable to all prevalent materials, equipped with four guiding rollers, easy-to-read scale (mm + inch), loops to hang from work belt, hand grip, expandable with a second Premium Edge Roller and adapter to become a dual bending machine.

91600000- 4.29LB, 11-3/4" x 5-7/8"

Equipped with four guiding rollers, easy-to-read scale (mm + inch), loops to hang from work belt, bending height: 1/4" – 7 7/8" .

91601000- 8.60LB, 14-5/8" x 11-3/4"

Adapter to become a dual bending machine.

91600001- 1.90LB, 13" x 7-1/8"

91600002- 1.76LB, 13" x 5-1/2"

91610001-2.32LB, 9-7/8" x 2"

91600004- 2.64LB, 8-7/8" x 19-1/4"

 Hand Grip for FREUND Maxi-, Premium- and Standard Edge Roller.

91600003- 0.77LB, 11-3/4" x 4-3/8"

0,63" stainless stell rods with laser making, stainless steel ball bearings, bending wheel at 80° ankles can be adjusted depending on the thickness of the materials, highest quality and functionality.

91640000- 2.87LB, 5,9"

Bending from 90°-180°, insertion depth from 0,32x1.0, material thickness up to 0,04" easy handling, perfect glide- and bending features.

91612000- 2.20LB, 5,5 x 3,9 x 4,7"
